Gilard 741-3131 – MICRO SWT.MINI.SPDT 5A WITH LONG LEVER

Description

Sub-miniature Micro Switch

Specifications

• Electrical
  • Rating 3A,250VAC,Contact resistance: <10m ohms and HV: >1.0KV –

• Climate
  • – 40 to + 80 degrees Celsius –

• Reference Standard

• Usage
  • Medical Equipment, Printers, Hand sets, Telecom, defence, automobile

• Life
  • Endurance at rated current @ room temperature – 25000 cycles

• Mechanical
  • Chassis Mounting – 9.5 mm pitch
  • Operating force – 90, 150, 210 grams
  • Pre travel – 0.6 mm max
  • Over travel – 0.6 mm min
  • Movement Differential – 0.2 mm max
  • Available in Solder, Quick Connect and PCB terminals –
  • Available in plain, with lever and lever roller variants –
  • Outer dimensions – 19.9 mm X 10.6 mm
