Description
| Sr. No. | Parameters | Specification |
|---|---|---|
| 1 | Type | Momentary/Latched, SPST |
| 2 | V/A Rating | 3.5VDC,480mA 3A 250V AC |
| 3 | Contact Resistance(Initial) | 10 m Ohms. Max. |
| 4 | Insulation Resistance at 500 V DC | 100 M Ohms Min. |
| 5 | H.V.Break Down Test(For 1-Minute) | 1 KV AC |
| 6 | Mounting | Panel, Screw-type |
| 7 | Terminals | Solder-type |
| 8 | Electrical Life | 10,000 Cycles. |
| 9 | Mechanical Life | 50,000 Cycles. |
| Sr. No. | Parameters | Specification |
|---|---|---|
| 1 | With/Without Load | -25°C to +85°C |
| 2 | For Soldering | 270°C for 5 Sec Max. |
| Sr. No. | Parameters | Specification |
|---|---|---|
| 1 | Body | Nylon |
| 2 | Contact housing | Nylon |
| 3 | Actuator | Nylon for PBS-1Series |
| 4 | Actuator | Nylon/Delrin for PBS-2 Series |
| 5 | Cap | ABS |
| 6 | Contacts, Terminals | Copper, Silver plated |
